SN74ALS870NSR
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
74ALS870 ROHS3Compliant Tape & Reel (TR) EAR99 shift register 17ns -2.6mA 15mm 5V
PDF
/
Inventory: 5195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 15mm
Technical
Memory IC Type STANDARD SRAM
Low Level Output Current 24mA
Parallel/Serial PARALLEL
High Level Output Current -2.6mA
Access Time (Max) 17 ns
Number of Bits per Element 4
Memory Width 4
Logic Type Register File
Propagation Delay 26 ns
Operating Mode ASYNCHRONOUS
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 2
Output Type Tri-State
Qualification Status Not Qualified
Function Universal
Base Part Number 74ALS870
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory Other Memory ICs
Additional Feature DUAL MEMORY FOR MULTIBUS ARCHITECTURE
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74ALS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 24
Package / Case 24-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
