SN74ALS165DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
ALS PARALLEL IN SERIAL OUT RoHS Compliant SOIC shift register 14ns 139.989945mg 45000000Hz 5.5V
PDF
/
Inventory: 9011
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Max Frequency@Nom-Sup 45000000Hz
fmax-Min 45 MHz
Number of Input Lines 9
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Logic IC Type PARALLEL IN SERIAL OUT
Output Polarity COMPLEMENTARY
Direction Unidirectional
Logic Function OR, Shift Register
Family ALS
Propagation Delay 14 ns
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Subcategory Shift Registers
Additional Feature CLOCK INHIBIT
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Physical
Weight 139.989945mg
Number of Pins 16
Package / Case SOIC
Mount Surface Mount
