SN54LS597J
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
TRUE Contains Lead DUAL POSITIVE EDGE shift register 30pF 125C 5V 35MHz
PDF
/
Inventory: 944
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 19.56mm
Height Seated (Max) 5.08mm
Technical
fmax-Min 35 MHz
Power Supply Current-Max (ICC) 53mA
Propagation Delay (tpd) 30 ns
Trigger Type POSITIVE EDGE
Logic IC Type PARALLEL IN SERIAL OUT
Output Polarity TRUE
Output Characteristics 3-STATE
Direction Unidirectional
Logic Function Shift Register
Family LS
Number of Bits 8
Load Capacitance 30pF
Temperature Grade MILITARY
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology TTL
HTS Code 8542.39.00.01
Additional Feature COMMON I/O PINS; MIXED SERIAL INPUTS; TOTEMPOLE SERIAL OUTPUT
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Terminations 16
Pbfree Code no
Physical
Surface Mount NO
Package / Case CDIP
