SN54HC166J
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
TRUE Contains Lead DUAL Through Hole shift register 50pF 125C 6V 25MHz
PDF
/
Buying Options
Total Price: USD $39.26
Unit Price: USD $39.2616
≥1 USD $39.2616
≥10 USD $32.2145
≥100 USD $31.20845
≥500 USD $30.20145
≥1000 USD $29.19445
Inventory: 1505
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Through Hole
Package / Case CDIP
Number of Pins 16
Technical
Packaging Rail/Tube
Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature SISO OPERATION ALSO AVAILABLE
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Pin Count 16
Operating Supply Voltage 5V
Number of Elements 1
Temperature Grade MILITARY
Max Supply Voltage 6V
Min Supply Voltage 2V
Load Capacitance 50pF
Number of Bits 8
Propagation Delay 225 ns
Turn On Delay Time 225 ns
Family HC/UH
Logic Function Shift Register
Direction Unidirectional
Output Polarity TRUE
Logic IC Type PARALLEL IN SERIAL OUT
Max I(ol) 0.0052 A
Prop. Delay@Nom-Sup 32 ns
Trigger Type POSITIVE EDGE
Schmitt Trigger No
fmax-Min 25 MHz
Dimensions
Height 5.08mm
Length 19.56mm
Width 6.92mm
Thickness 4.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
