SN54HC165J
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
COMPLEMENTARY Contains Lead DUAL Through Hole shift register 50pF 125C 6V 25MHz
PDF
/
Buying Options
Total Price: USD $3.71
Unit Price: USD $3.7126
≥1 USD $3.7126
≥10 USD $3.04665
≥100 USD $2.95165
≥500 USD $2.8557
≥1000 USD $2.7607
Inventory: 14313
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 4.57mm
Width 6.92mm
Length 19.56mm
Height 5.08mm
Technical
fmax-Min 25 MHz
Schmitt Trigger No
Trigger Type POSITIVE EDGE
Max I(ol) 0.0052 A
Logic IC Type PARALLEL IN SERIAL OUT
Output Polarity COMPLEMENTARY
Direction Unidirectional
Logic Function Shift Register
Family HC/UH
Turn On Delay Time 225 ns
Propagation Delay 225 ns
Number of Bits 8
Load Capacitance 50pF
Min Supply Voltage 2V
Max Supply Voltage 6V
Temperature Grade MILITARY
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Additional Feature SISO OPERATION ALSO AVAILABLE
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 16
Packaging Rail/Tube
Physical
Number of Pins 16
Package / Case CDIP
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
