CD74HCT194EE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
IC 4BIT BI-DIR SHIFT REG 16-DIP
PDF
/
Inventory: 6565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 5.08mm
Technical
Number of Input Lines 6
Trigger Type POSITIVE EDGE
Number of Bits per Element 4
Logic IC Type PARALLEL IN PARALLEL OUT
Output Polarity TRUE
Direction Bidirectional
Logic Function Shift Register
Family HCT
Turn On Delay Time 60 ns
Propagation Delay 37 ns
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade MILITARY
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Additional Feature HOLD MODE
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Pbfree Code yes
JESD-609 Code e4
Packaging Rail/Tube
Physical
Weight 951.693491mg
Number of Pins 16
Package / Case PDIP
Mount Through Hole
