CD74HCT164MTG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HCT SERIAL IN PARALLEL OUT RoHS Compliant Tape & Reel (TR) shift register 36ns 129.387224mg 5.5V 125C
PDF
/
Inventory: 1864
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Technical
Number of Input Lines 2
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Logic IC Type SERIAL IN PARALLEL OUT
Output Polarity TRUE
Direction Unidirectional
Logic Function Shift Register
Family HCT
Turn On Delay Time 57 ns
Propagation Delay 36 ns
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Temperature Grade MILITARY
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 14
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case SOIC
Mount Surface Mount
