CD74HC194PW
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HC/UH 74HC194 ROHS3Compliant Tube shift register 37ns 0.08mA 61.887009mg 60MHz
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.03312
≥100 USD $0.805394
Inventory: 283
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
fmax-Min 23 MHz
Input Current 1μA
Number of Input Lines 6
Power Supply Current-Max (ICC) 0.08mA
Schmitt Trigger No
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 37 ns
Number of Bits per Element 4
Max I(ol) 0.0052 A
Output Polarity TRUE
Logic Type Register, Bidirectional
Direction Bidirectional
Logic Function Shift Register
Family HC/UH
Turn On Delay Time 265 ns
Quiescent Current 8μA
Propagation Delay 265 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Operating Supply Voltage 5V
Output Type Push-Pull
Function Universal
Base Part Number 74HC194
Frequency 60MHz
Supply Voltage 4.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Additional Feature HOLD MODE
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
