CD74HC164MTG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HC/UH SERIAL IN PARALLEL OUT RoHS Compliant SOIC shift register 29ns 129.387224mg 6V 125C
PDF
/
Inventory: 4443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Technical
Number of Input Lines 2
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Logic IC Type SERIAL IN PARALLEL OUT
Output Polarity TRUE
Direction Unidirectional
Logic Function Shift Register
Family HC/UH
Turn On Delay Time 255 ns
Propagation Delay 29 ns
Min Supply Voltage 2V
Max Supply Voltage 6V
Temperature Grade MILITARY
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 14
Supply Voltage 4.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case SOIC
Mount Surface Mount
