CD4094BNSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
CD4094 ROHS3Compliant Tape & Reel (TR) EAR99 shift register 250ns 0.3mA 200.686274mg 3MHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.47696
≥100 USD $0.444928
≥500 USD $0.355872
≥1000 USD $0.330458
≥3000 USD $0.279611
Inventory: 1430
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.3mm
Height 2mm
Technical
fmax-Min 3 MHz
Number of Output Lines 10
Number of Input Lines 1
Power Supply Current-Max (ICC) 0.3mA
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 250 ns
Number of Bits per Element 8
Output Polarity TRUE
Logic Type Shift Register
Output Characteristics 3-STATE
Direction Unidirectional
Logic Function Latch, Shift Register
Turn On Delay Time 840 ns
Quiescent Current 100μA
Propagation Delay 840 ns
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Operating Supply Voltage 15V
Output Type Tri-State
Function Serial to Parallel
Base Part Number CD4094
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method TR
Additional Feature COMPLIMENTARY SERIAL OUTPUT ALSO AVAILABLE
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
