CD4035BMT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
CD4035 ROHS3Compliant Tape & Reel (TR) e4 shift register 150ns 100nA 141.690917mg 16MHz
PDF
/
Inventory: 1537
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Termination SMD/SMT
Additional Feature J AND K BAR SERIAL INPUT
Max Power Dissipation 100mW
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 16MHz
Base Part Number CD4035
Function Parallel or Serial to Serial
Output Type Complementary
Operating Supply Voltage 15V
Number of Elements 1
Supply Voltage-Min (Vsup) 3V
Propagation Delay 150 ns
Quiescent Current 100μA
Turn On Delay Time 500 ns
Logic Function OR, Shift Register
Direction Unidirectional
Logic Type Shift Register
Output Polarity CONFIGURABLE
Number of Bits per Element 4
Trigger Type POSITIVE EDGE
Max Input Current 100nA
Number of Input Lines 6
fmax-Min 8 MHz
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
