CD4031BPW
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
CD4031 ROHS3Compliant Tube e4 shift register 180ns 100nA 61.887009mg 12MHz
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.5136
≥1 USD $1.5136
≥10 USD $1.36136
≥100 USD $1.094227
≥500 USD $1.027453
Inventory: 549
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
fmax-Min 6 MHz
Number of Output Lines 3
Input Current 100nA
Number of Input Lines 2
Schmitt Trigger No
Trigger Type POSITIVE EDGE
Number of Bits per Element 4
Logic Type Register, D-Type
Direction Unidirectional
Logic Function Shift Register
Turn On Delay Time 500 ns
Quiescent Current 100μA
Propagation Delay 180 ns
Number of Bits 64
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Operating Supply Voltage 15V
Output Type Complementary
Qualification Status Not Qualified
Function Universal
Base Part Number CD4031
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 12MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Additional Feature DELAYED BUFFERED CLOCK OUTPUT FOR CASCADING
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
