8101701EA
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
PARALLEL IN PARALLEL OUT RoHS Compliant CDIP MIL-STD-883 shift register 200ns 0.3mA 5.08mm 2000000Hz
PDF
/
Buying Options
Total Price: USD $18.91
Unit Price: USD $18.9112
≥1 USD $18.9112
Inventory: 243
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Through Hole
Package / Case CDIP
Number of Pins 16
Technical
Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature J AND K BAR SERIAL INPUT
Packing Method TUBE
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Pin Count 16
Qualification Status Qualified
Number of Elements 1
Temperature Grade MILITARY
Max Supply Voltage 18V
Min Supply Voltage 3V
Load Capacitance 50pF
Number of Bits 4
Propagation Delay 500 ns
Quiescent Current 100μA
Logic Function Shift Register
Direction Unidirectional
Output Polarity CONFIGURABLE
Logic IC Type PARALLEL IN PARALLEL OUT
Prop. Delay@Nom-Sup 200 ns
Screening Level MIL-STD-883
Trigger Type POSITIVE EDGE
Schmitt Trigger No
Power Supply Current-Max (ICC) 0.3mA
fmax-Min 8 MHz
Max Frequency@Nom-Sup 2000000Hz
Dimensions
Height 5.08mm
Length 19.56mm
Width 6.92mm
Thickness 4.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
