M74HC166B1R
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HC/UH M74HC166 ROHS3Compliant Tube shift register 26ns 2.54mm 25000000Hz 2V
PDF
/
Buying Options
Total Price: USD $37.06
Unit Price: USD $37.062871
≥1 USD $37.062871
≥10 USD $34.964973
≥100 USD $32.985826
≥500 USD $31.118698
≥1000 USD $29.357268
Inventory: 1590
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
Max Frequency@Nom-Sup 25000000Hz
Count Direction RIGHT
fmax-Min 25 MHz
Number of Input Lines 9
Trigger Type POSITIVE EDGE
Output Polarity TRUE
Logic Type Shift Register
Logic Function OR, Shift Register
Family HC/UH
Turn On Delay Time 225 ns
Propagation Delay 26 ns
Number of Bits 8
Load Capacitance 50pF
Number of Circuits 8
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/6V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Output Type Push-Pull
Qualification Status Not Qualified
Function Parallel or Serial to Serial
Base Part Number M74HC166
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 4.5V
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Additional Feature CLOCK INHIBIT
Terminal Finish Matte Tin (Sn)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
