MC14015BD
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
4015 Non-RoHS Compliant Tube 2005 shift register 170ns 3.9mm 3.75MHz 3V
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3192
≥1 USD $0.3192
≥10 USD $0.2622
≥100 USD $0.25365
≥500 USD $0.24605
≥1000 USD $0.2375
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 133mm
Diameter 9.8mm
Technical
Max Frequency@Nom-Sup 3750000Hz
Count Direction RIGHT
fmax-Min 3.75 MHz
Number of Input Lines 1
Number of Bits per Element 4
Output Polarity TRUE
Logic Type Shift Register
Logic Function Shift Register
Propagation Delay 170 ns
Supply Voltage-Min (Vsup) 3V
Number of Elements 2
Output Type Push-Pull
Qualification Status Not Qualified
Function Serial to Parallel
Base Part Number 4015
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series 4000B
Published 2005
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Material Steel
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
