74HCT4094D,112
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HCT 74HCT4094 ROHS3Compliant Tube shift register 65ns 9.9mm 20MHz 4.5V
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
Inventory: 1089
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2011
Series 74HCT
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature PARALLEL OUTPUT IS LATCHED; UNLATCHED SERIAL SHIFT RIGHT OUTPUT
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74HCT4094
Function Serial to Parallel, Serial
Output Type Tri-State
Number of Elements 1
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Family HCT
Output Characteristics 3-STATE
Logic Type Shift Register
Output Polarity TRUE
Number of Bits per Element 8
Trigger Type POSITIVE EDGE
Propagation Delay (tpd) 65 ns
fmax-Min 20 MHz
Count Direction RIGHT
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
