CD74ACT280E
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Parity Generators and Checkers
Description
ACT 74ACT e4 ACTIVE (Last Updated: 5days ago) parity generator checker 5.08mm -55C~125C 21.6ns 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.13
Unit Price: USD $1.1264
≥1 USD $1.1264
≥10 USD $1.00936
≥100 USD $0.958144
≥500 USD $0.787072
≥1000 USD $0.735715
≥3000 USD $0.650162
Inventory: 667
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Power Supply Current-Max (ICC) 0.08mA
Max I(ol) 0.075 A
Output Polarity COMPLEMENTARY
Logic Type Parity Generator/Checker
Current - Output High, Low 24mA 24mA
Family ACT
Turn On Delay Time 21.6 ns
Quiescent Current 8μA
Propagation Delay 21.6 ns
Number of Bits 2
Max Supply Current 8μA
Output Current 24mA
Load Capacitance 50pF
Number of Circuits 9-Bit
Number of Channels 9
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Max Output Current 50mA
Qualification Status Not Qualified
Pin Count 14
Base Part Number 74ACT280
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Arithmetic Circuits
Additional Feature ODD/EVEN PARITY GENERATOR
Termination Through Hole
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 74ACT
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 927.99329mg
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
