SN74AHC123ADR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description ACTIVE (Last Updated: 3days ago) e4 74AHC123 74AHC multivibrator 2V~5.5V 1.75mm 0.008A 7.5ns
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.3168
≥100 USD $0.29568
≥500 USD $0.236456
≥1000 USD $0.219613
≥3000 USD $0.185821
Inventory: 1652
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg

Technical

Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
Series 74AHC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Packing Method TR
Technology CMOS
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 3.3V
Base Part Number 74AHC123
Pin Count 16
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 2V
Number of Circuits 2
Load Capacitance 50pF
Output Current 8mA
Number of Bits 2
Propagation Delay 7.5ns
Quiescent Current 4μA
Turn On Delay Time 29.5 ns
Family AHC/VHC/H/U/V
Logic Function Multivibrator
Current - Output High, Low 8mA 8mA
Logic Type Monostable
Output Polarity COMPLEMENTARY
Max I(ol) 0.008 A
Power Supply Current-Max (ICC) 0.04mA
Schmitt Trigger Input Yes
Number of Data/Clock Inputs 2

Dimensions

Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
