CD74HC123PWRE4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
ACTIVE (Last Updated: 1week ago) e4 74HC123 74HC multivibrator 2V~6V 1.2mm 5.2mA 5.2mA 25ns
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.22599
≥1 USD $0.22599
≥200 USD $0.087466
≥500 USD $0.084393
≥1000 USD $0.08287
Inventory: 992
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Number of Data/Clock Inputs 2
Schmitt Trigger Input No
Power Supply Current-Max (ICC) 0.08mA
Output Polarity COMPLEMENTARY
Logic Type Monostable
Current - Output High, Low 5.2mA 5.2mA
Logic Function Multivibrator
Family HC/UH
Turn On Delay Time 54 ns
Quiescent Current 8μA
Propagation Delay 25ns
Number of Bits 2
Output Current 5.2mA
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Number of Elements 2
Operating Supply Voltage 5V
Pin Count 16
Base Part Number 74HC123
Supply Voltage 4.5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Additional Feature RETRIGGERABLE
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 61.887009mg
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
