M74HC221RM13TR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
e4 M74HC221 74HC Tape & Reel (TR) multivibrator 2V~6V 500mW 6.35mm 5.2mA 5.2mA
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.5479
≥1 USD $2.5479
≥10 USD $2.09095
≥100 USD $2.0254
≥500 USD $1.95985
≥1000 USD $1.89525
Inventory: 1953
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 6.39999g
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74HC
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Termination SMD/SMT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation 500mW
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 4.5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M74HC221
Pin Count 16
Operating Supply Voltage 5V
Number of Elements 2
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Output Current 5.2mA
Max Supply Current 4μA
Propagation Delay 24ns
Quiescent Current 4μA
Turn On Delay Time 36 ns
Family HC/UH
Logic Function Multivibrator
Number of Inputs 4
Current - Output High, Low 5.2mA 5.2mA
Logic Type Monostable
Rise Time 400ns
Output Polarity COMPLEMENTARY
Schmitt Trigger Input Yes
Number of Data/Clock Inputs 2
Dimensions
Height 6.35mm
Length 19.05mm
Width 12.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
