CD74HCT4538M
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
COMPLEMENTARY GULL WING CMOS Obsolete Monostable Multivibrator -55C~125C 23ns 4mA 4mA 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.21176
≥100 USD $1.14972
≥500 USD $0.94446
Inventory: 328
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Number of Data/Clock Inputs 2
Schmitt Trigger Input Yes
Independent Circuits 2
Output Polarity COMPLEMENTARY
Logic Type Monostable
Current - Output High, Low 4mA 4mA
Family HCT
Propagation Delay 23ns
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G16
Supply Voltage 5V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Additional Feature RETRIGGERABLE
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74HCT
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
