MC14538BF
RoHS
/
Package 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
Multivibrator COMPLEMENTARY Contains Lead GULL WING Monostable Multivibrator -55C~125C 95ns 8.8mA 8.8mA 3V~18V
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.41515
≥1 USD $0.41515
≥10 USD $0.34105
≥100 USD $0.32965
≥500 USD $0.3192
≥1000 USD $0.30875
Inventory: 8405
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Number of Data/Clock Inputs 2
Schmitt Trigger Input Yes
Independent Circuits 2
Output Polarity COMPLEMENTARY
Logic Type Monostable
Current - Output High, Low 8.8mA 8.8mA
Logic Function Multivibrator
Family 4000/14000/40000
Propagation Delay 95ns
Supply Voltage-Min (Vsup) 3V
Power Supplies 5/15V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 12V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number 4538
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series 4000B
Published 2011
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
