74HCT4538D,112
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
e4 74HCT4538 2011 74HCT multivibrator 4.5V~5.5V 1.75mm 4mA 4mA 35ns
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.16527
≥1 USD $1.16527
≥10 USD $1.09931
≥100 USD $1.03708
≥500 USD $0.97838
≥1000 USD $0.923
Inventory: 6018
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2011
Series 74HCT
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature RETRIGGERABLE
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 5V
Base Part Number 74HCT4538
Pin Count 16
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Output Current 4mA
Propagation Delay 35ns
Family HCT
Current - Output High, Low 4mA 4mA
Logic Type Monostable
Output Polarity COMPLEMENTARY
Independent Circuits 2
Schmitt Trigger Input No
Number of Data/Clock Inputs 2
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
