SN74LVC841APWR
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74LVC841 Cut Tape (CT) LVC/LCX/Z 74LVC latch circuit 6.7ns 24mA 24mA 8.6ns 89.499445mg
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.74515
≥1 USD $1.74515
≥10 USD $1.4326
≥100 USD $1.38795
≥500 USD $1.34235
≥1000 USD $1.2977
Inventory: 2004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 7.8mm
Height 1.2mm
Technical
Translation N/A
Number of Output Lines 3
Independent Circuits 1
Control Type ENABLE LOW/HIGH
Prop. Delay@Nom-Sup 6.7 ns
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Logic Function D-Type, Latch
Family LVC/LCX/Z
Turn On Delay Time 2.7 ns
Propagation Delay 8.6 ns
Number of Bits 10
Output Current 24mA
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Polarity Non-Inverting
Circuit 10:10
Output Type Tri-State
Pin Count 24
Base Part Number 74LVC841
Terminal Pitch 0.65mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~3.6V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LVC
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Weight 89.499445mg
Number of Pins 24
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
