SN74LVC841ADWR
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete CMOS latch circuit 50pF -40C~85C 2.65mm 6.7ns
PDF
/
Inventory: 1683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Number of Output Lines 10
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family LVC/LCX/Z
Turn On Delay Time 2.7 ns
Propagation Delay 6.7 ns
Number of Bits 10
Number of Ports 2
Load Capacitance 50pF
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Polarity Non-Inverting
Circuit 10:10
Number of Elements 1
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 24
Base Part Number 74LVC841
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~3.6V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74LVC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
