SN74LVC373APWG4
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
ENABLE LOW Surface Mount ROHS3Compliant Active D-Type Transparent Latch 50pF -40C~85C 76.997305mg 8.7ns
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.378614
≥1 USD $0.378614
≥200 USD $0.146519
≥500 USD $0.141373
≥1000 USD $0.138826
Inventory: 1195
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
Technical
Count Direction UNIDIRECTIONAL
Independent Circuits 1
Number of Input Lines 8
Control Type ENABLE LOW
Max I(ol) 0.024 A
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family LVC/LCX/Z
Turn On Delay Time 1.5 ns
Propagation Delay 8.7 ns
Number of Bits 8
Output Current 24mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Polarity Non-Inverting
Circuit 8:8
Output Type Tri-State
Pin Count 20
Base Part Number 74LVC373
Terminal Pitch 0.65mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~3.6V
Technology CMOS
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LVC
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 76.997305mg
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
