SN74LV373ATDBR
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF -40C~85C 156.687814mg 9.5ns
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.265851
≥1 USD $0.265851
≥10 USD $0.250802
≥100 USD $0.236601
≥500 USD $0.223217
≥1000 USD $0.210581
Inventory: 5699
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 7.2mm
Height Seated (Max) 2mm
Technical
Number of Output Lines 8
Logic Type D-Type Transparent Latch
Current - Output High, Low 16mA 16mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family LV/LV-A/LVX/H
Turn On Delay Time 1 ns
Propagation Delay 9.5 ns
Number of Bits 8
Output Current 16mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 3.3V
Polarity Non-Inverting
Circuit 8:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 20
Base Part Number 74LV373
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74LV
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 156.687814mg
Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
