SN74F2373DBR
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74F2373 Tape & Reel (TR) F/FAST 74F latch circuit 9ns 3mA 12mA 7ns 7.2mm
PDF
/
Inventory: 1163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 7.2mm
Height Seated (Max) 2mm
Technical
Independent Circuits 1
Number of Input Lines 8
Prop. Delay@Nom-Sup 9 ns
Logic Type D-Type Transparent Latch
Current - Output High, Low 3mA 12mA
Output Characteristics 3-STATE WITH SERIES RESISTOR
Logic Function D-Type, Latch
Family F/FAST
Turn On Delay Time 7.3 ns
Propagation Delay 7 ns
Number of Bits 8
Nominal Supply Current 66mA
Number of Ports 2
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Circuit 8:8
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 20
Base Part Number 74F2373
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Packing Method TAPE AND REEL
Subcategory FF/Latches
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74F
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
