SN74BCT29843NT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Through Hole ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF 0C~70C 1.753503g 8ns
PDF
/
Buying Options
Total Price: USD $1.91
Unit Price: USD $1.9096
≥1 USD $1.9096
Inventory: 850
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.300, 7.62mm)
Number of Pins 24
Weight 1.753503g
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74BCT
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Additional Feature WITH CLEAR AND PRESET
Subcategory FF/Latches
Technology BICMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74BCT29843
Pin Count 20
Number of Outputs 9
Qualification Status Not Qualified
Output Type Tri-State
Circuit 9:9
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 9
Propagation Delay 8 ns
Turn On Delay Time 6 ns
Family BCT/FBT
Logic Function D-Type, Latch
Output Characteristics 3-STATE
Current - Output High, Low 24mA 48mA
Logic Type D-Type Transparent Latch
Max I(ol) 0.048 A
Power Supply Current-Max (ICC) 35mA
Independent Circuits 1
Dimensions
Height Seated (Max) 5.08mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
