SN74ALVCH162260DLR
RoHS
RoHS compliant
RoHS compliantPackage 56-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74ALVCH162260 Tape & Reel (TR) ALVC/VCX/A 74ALVCH latch circuit 5.9ns 12mA 12mA 7.2ns 694.790113mg
PDF
/
Buying Options
Total Price: USD $2.04
Unit Price: USD $2.0416
≥1 USD $2.0416
≥10 USD $1.83216
≥100 USD $1.728672
≥500 USD $1.472856
≥1000 USD $1.382973
≥3000 USD $1.210106
Inventory: 1046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 56-BSSOP (0.295, 7.50mm Width)
Number of Pins 56
Weight 694.790113mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74ALVCH
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 56
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Logic ICs
Packing Method TR
Technology CMOS
Voltage - Supply 1.65V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 1.8V
Terminal Pitch 0.635mm
Base Part Number 74ALVCH162260
Pin Count 56
Number of Outputs 24
Output Type Tri-State
Circuit 12:24
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Load Capacitance 50pF
Output Current 24mA
Number of Bits 12
Propagation Delay 7.2 ns
Turn On Delay Time 1 ns
Family ALVC/VCX/A
Logic Function D-Type, Latch
Output Characteristics 3-STATE WITH SERIES RESISTOR
Current - Output High, Low 12mA 12mA
Logic Type D-Type, Addressable
Prop. Delay@Nom-Sup 5.9 ns
Power Supply Current-Max (ICC) 0.04mA
Independent Circuits 1
Dimensions
Height 2.79mm
Length 18.41mm
Width 7.49mm
Thickness 2.59mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
