SN74ALS996-1NT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Through Hole ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF 0C~70C 1.753503g 30ns
PDF
/
Buying Options
Total Price: USD $82.96
Unit Price: USD $82.96255
≥1 USD $82.96255
≥10 USD $80.37
≥100 USD $77.77745
≥500 USD $75.1849
≥1000 USD $67.40725
Inventory: 1503
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Technical
Independent Circuits 1
Number of Input Lines 8
Logic Type D-Type Transparent Latch
Current - Output High, Low 400μA 8mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family ALS
Turn On Delay Time 5 ns
Propagation Delay 30 ns
Number of Bits 8
Output Current 48mA
Nominal Supply Current 85mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Circuit 8:8
Operating Supply Voltage 5V
Output Type Tri-State
Pin Count 24
Base Part Number 74ALS996
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory Bus Driver/Transceiver
Additional Feature WITH READ-BACK; WITH MASTER CONTROL FOR CLOCK AND READ INPUT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ALS
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 1.753503g
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
