SN74ALS667DWR
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF 0C~70C 624.398247mg 20ns
PDF
/
Buying Options
Total Price: USD $30.97
Unit Price: USD $30.965164
≥1 USD $30.965164
≥10 USD $29.212421
≥100 USD $27.558886
≥500 USD $25.998953
≥1000 USD $24.527313
Inventory: 3173
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Number of Output Lines 8
Logic Type D-Type Transparent Latch
Current - Output High, Low 400μA 8mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family ALS
Turn On Delay Time 9 ns
Propagation Delay 20 ns
Number of Bits 8
Output Current 24mA
Nominal Supply Current 79mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Inverting
Circuit 8:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 24
Base Part Number 74ALS667
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Packing Method TAPE AND REEL
Subcategory FF/Latches
Additional Feature WITH CLEAR AND PRESET; WITH DUAL OUTPUT ENABLE; WITH READ-BACK
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74ALS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 624.398247mg
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
