SN74ABT16843DLR
RoHS
RoHS compliant
RoHS compliantPackage 56-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete Contains Lead D-Type Transparent Latch 50pF -40C~85C 694.790113mg 4.2ns
PDF
/
Buying Options
Total Price: USD $3.64
Unit Price: USD $3.6442
≥1 USD $3.6442
≥10 USD $2.98965
≥100 USD $2.89655
≥500 USD $2.80345
≥1000 USD $2.7094
Inventory: 9467
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Technical
Number of Output Lines 18
Power Supply Current-Max (ICC) 85mA
Prop. Delay@Nom-Sup 4.8 ns
Max I(ol) 0.064 A
Logic Type D-Type Transparent Latch
Current - Output High, Low 32mA 64mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family ABT
Turn On Delay Time 4 ns
Propagation Delay 4.2 ns
Number of Bits 18
Output Current 64mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Circuit 9:9
Number of Elements 2
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 56
Base Part Number 74ABT16843
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Additional Feature WITH CLEAR AND PRESET
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74ABT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 694.790113mg
Number of Pins 56
Package / Case 56-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
