CY74FCT373CTSOCT
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF -40C~85C 2.65mm 4.7ns
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.236353
≥1 USD $1.236353
≥10 USD $1.166371
≥100 USD $1.100349
≥500 USD $1.038072
≥1000 USD $0.979306
Inventory: 8574
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74FCT
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74FCT373
Pin Count 20
Qualification Status Not Qualified
Output Type Tri-State
Circuit 8:8
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Load Capacitance 50pF
Number of Ports 2
Nominal Supply Current 200μA
Output Current 64mA
Number of Bits 8
Propagation Delay 4.7 ns
Quiescent Current 100μA
Turn On Delay Time 2 ns
Family FCT
Logic Function D-Type, Latch
Output Characteristics 3-STATE
Current - Output High, Low 32mA 64mA
Logic Type D-Type Transparent Latch
Max I(ol) 0.064 A
Independent Circuits 1
Number of Output Lines 8
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
