CY74FCT373CTSOC
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete Lead Free D-Type Transparent Latch 50pF -40C~85C 2.65mm 4.7ns
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.40635
≥1 USD $2.40635
≥10 USD $1.9741
≥100 USD $1.91235
≥500 USD $1.8506
≥1000 USD $1.78885
Inventory: 8003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Independent Circuits 1
Number of Input Lines 8
Max I(ol) 0.064 A
Logic Type D-Type Transparent Latch
Current - Output High, Low 32mA 64mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family FCT
Turn On Delay Time 2 ns
Quiescent Current 100μA
Propagation Delay 4.7 ns
Number of Bits 8
Output Current 64mA
Nominal Supply Current 200μA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Circuit 8:8
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 20
Base Part Number 74FCT373
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory FF/Latches
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74FCT
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
