CY74FCT373ATSOCT
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Discontinued Contains Lead D-Type Transparent Latch 50pF -40C~85C 500.709277mg 5.2ns
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.814189
≥1 USD $1.814189
≥10 USD $1.711506
≥100 USD $1.614625
≥500 USD $1.523235
≥1000 USD $1.437005
Inventory: 1711
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Number of Output Lines 8
Max I(ol) 0.064 A
Logic Type D-Type Transparent Latch
Current - Output High, Low 32mA 64mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family FCT
Turn On Delay Time 2 ns
Quiescent Current 100μA
Propagation Delay 5.2 ns
Number of Bits 8
Output Current 64mA
Nominal Supply Current 200μA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Circuit 8:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State
Pin Count 20
Base Part Number 74FCT373
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Series 74FCT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 500.709277mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
