CD74HC563MG4
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74HC563 Tube HC/UH 74HC latch circuit 45ns 7.8mA 7.8mA 26ns 2.65mm
PDF
/
Inventory: 1566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 74HC
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Additional Feature BROADSIDE VERSION OF 533
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 4.5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74HC563
Pin Count 20
Qualification Status Not Qualified
Output Type Tri-State
Circuit 8:8
Polarity Inverting
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Number of Ports 2
Output Current 7.8mA
Number of Bits 8
Propagation Delay 26 ns
Turn On Delay Time 12 ns
Family HC/UH
Logic Function D-Type, Latch
Output Characteristics 3-STATE
Current - Output High, Low 7.8mA 7.8mA
Logic Type D-Type Transparent Latch
Max I(ol) 0.006 A
Prop. Delay@Nom-Sup 45 ns
Independent Circuits 1
Number of Output Lines 8
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
