74AC16373DLRG4
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74AC16373 Tape & Reel (TR) AC 74AC latch circuit 10ns 24mA 24mA 22.3ns 600.301152mg
PDF
/
Inventory: 1436
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Number of Pins 48
Weight 600.301152mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74AC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Subcategory FF/Latches
Packing Method TR
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.635mm
Base Part Number 74AC16373
Pin Count 48
Output Type Tri-State
Operating Supply Voltage 5V
Number of Elements 2
Circuit 8:8
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Number of Ports 2
Output Current 24mA
Number of Bits 16
Propagation Delay 22.3 ns
Quiescent Current 8μA
Turn On Delay Time 10.6 ns
Family AC
Logic Function D-Type, Latch
Translation N/A
Count Direction UNIDIRECTIONAL
Number of Output Lines 16
Power Supply Current-Max (ICC) 0.08mA
Control Type ENABLE LOW/HIGH
Prop. Delay@Nom-Sup 10 ns
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.59mm
Width 7.49mm
Length 15.88mm
Height 2.79mm
