74VHCT373AMTR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74VHCT373 Tape & Reel (TR) AHCT/VHCT 74VHCT latch circuit 8mA 8mA 13.3ns 2.65mm -55C~125C
PDF
/
Inventory: 1472
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74VHCT
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74VHCT373
Pin Count 20
Qualification Status Not Qualified
Output Type Tri-State
Operating Supply Voltage 5V
Circuit 8:8
Polarity Non-Inverting
Power Supplies 5V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 13.3 ns
Turn On Delay Time 6.4 ns
Family AHCT/VHCT
Logic Function D-Type, Latch
Current - Output High, Low 8mA 8mA
Logic Type D-Type Transparent Latch
Number of Input Lines 8
Independent Circuits 1
Number of Output Lines 3
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
