74V1G77CTR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / Logic - Latches
Description 74V1G77 Tape & Reel (TR) 74V 74V latch circuit 8mA 8mA 7ns 2mm -55C~125C
PDF
/
Inventory: 1498
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Number of Pins 5

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74V
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 5
Terminal Finish Matte Tin (Sn)
Subcategory FF/Latches
Packing Method TAPE AND REEL
Technology CMOS
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74V1G77
Pin Count 5
Output Type Standard
Circuit 1:1
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 2V
Number of Bits 1
Propagation Delay 7 ns
Turn On Delay Time 4.8 ns
Family 74V
Logic Function D-Type, Latch
Current - Output High, Low 8mA 8mA
Logic Type D-Type Transparent Latch
Max I(ol) 0.004 A
Trigger Type HIGH LEVEL
Number of Input Lines 1

Dimensions

Length 2mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
