CD74AC573E
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
TRUE Through Hole Non-RoHS Compliant Obsolete D-Type Transparent Latch -55C~125C 25.4mm 3ns 24mA 24mA
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
Inventory: 10385
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 74AC
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Terminal Finish NICKEL PALLADIUM GOLD
Additional Feature BROADSIDE VERSION OF 373
Technology CMOS
Voltage - Supply 1.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
JESD-30 Code R-PDIP-T20
Output Type Tri-State
Circuit 8:8
Supply Voltage-Max (Vsup) 5.5V
Number of Ports 2
Number of Bits 8
Family AC
Output Characteristics 3-STATE
Current - Output High, Low 24mA 24mA
Logic Type D-Type Transparent Latch
Output Polarity TRUE
Independent Circuits 1
Delay Time - Propagation 3ns
Dimensions
Height Seated (Max) 5.08mm
Length 25.4mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
