CD4043BE
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
TRUE Through Hole Non-RoHS Compliant HIGH LEVEL S-R Latch -55C~125C 19.17mm 50ns 6.8mA 6.8mA
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
Inventory: 6377
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series 4000B
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Terminal Finish NICKEL PALLADIUM GOLD
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
JESD-30 Code R-PDIP-T16
Qualification Status Not Qualified
Output Type Tri-State
Circuit 1:1
Supply Voltage-Max (Vsup) 18V
Supply Voltage-Min (Vsup) 3V
Number of Bits 4
Output Characteristics 3-STATE
Current - Output High, Low 6.8mA 6.8mA
Logic Type S-R Latch
Output Polarity TRUE
Trigger Type HIGH LEVEL
Independent Circuits 4
Delay Time - Propagation 50ns
Dimensions
Height Seated (Max) 5.33mm
Length 19.17mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
