74F573SJ
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Tube F/FAST 74F GULL WING latch circuit 3mA 24mA 5.3ns 5.3mm 0C~70C
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
Inventory: 3102
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74F
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish MATTE TIN
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Output Type Tri-State
Circuit 8:8
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Number of Ports 2
Number of Bits 8
Family F/FAST
Output Characteristics 3-STATE
Current - Output High, Low 3mA 24mA
Logic Type D-Type Transparent Latch
Output Polarity TRUE
Independent Circuits 1
Delay Time - Propagation 5.3ns
Dimensions
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
