MC74LCX573DW
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount Non-RoHS Compliant Obsolete Contains Lead D-Type Transparent Latch 50pF -55C~125C 2.65mm 8ns
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.036939
≥1 USD $1.036939
≥10 USD $0.978246
≥100 USD $0.922874
≥500 USD $0.870636
≥1000 USD $0.821355
Inventory: 5988
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2009
Series 74LCX
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory FF/Latches
Packing Method RAIL
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 2.5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74LCX573
Pin Count 20
Qualification Status Not Qualified
Output Type Tri-State
Circuit 8:8
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 2V
Number of Circuits 8
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 8 ns
Turn On Delay Time 1.5 ns
Family LVC/LCX/Z
Logic Function D-Type, Latch
Current - Output High, Low 24mA 24mA
Logic Type D-Type Transparent Latch
Max I(ol) 0.024 A
Number of Input Lines 3
Independent Circuits 1
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
