MC74ACT259NG
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Through Hole RoHS Compliant LOW LEVEL Obsolete D-Type, Addressable 50pF -40C~85C 4.44mm 11ns
PDF
/
Buying Options
Total Price: USD $50.02
Unit Price: USD $50.016769
≥1 USD $50.016769
≥10 USD $47.185628
≥100 USD $44.514752
≥500 USD $41.995051
≥1000 USD $39.617972
Inventory: 9333
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Height Seated (Max) 4.44mm
Technical
Trigger Type LOW LEVEL
Max I(ol) 0.024 A
Logic Type D-Type, Addressable
Current - Output High, Low 24mA 24mA
Logic Function D-Type, Shift Register
Family ACT
Turn On Delay Time 6.5 ns
Propagation Delay 11 ns
Number of Bits 8
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Circuit 1:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Standard
Pin Count 16
Base Part Number 74ACT259
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method RAIL
Subcategory FF/Latches
Terminal Finish Tin (Sn)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74ACT
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
