MC74AC259MG
RoHS
/
Package 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount RoHS Compliant LOW LEVEL Obsolete D-Type, Addressable 50pF -40C~85C 2.05mm 10ns
PDF
/
Buying Options
Total Price: USD $1.76
Unit Price: USD $1.761961
≥1 USD $1.761961
≥10 USD $1.662224
≥100 USD $1.568139
≥500 USD $1.479379
≥1000 USD $1.39564
Inventory: 7999
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.275mm
Height Seated (Max) 2.05mm
Technical
Trigger Type LOW LEVEL
Logic Type D-Type, Addressable
Current - Output High, Low 24mA 24mA
Logic Function D-Type, Shift Register
Family AC
Turn On Delay Time 6.5 ns
Propagation Delay 10 ns
Number of Bits 8
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Circuit 1:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Standard
Qualification Status Not Qualified
Pin Count 16
Base Part Number 74AC259
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method RAIL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series 74AC
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
