MC74AC259DG
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
74AC259 Tube AC 74AC latch circuit 24mA 24mA 22.5ns 665.986997mg -40C~85C
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.804
≥1 USD $1.804
≥10 USD $1.62184
≥100 USD $1.5301
≥500 USD $1.224115
≥1000 USD $1.071092
≥3000 USD $1.040486
Inventory: 870
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 10mm
Height 1.5mm
Technical
Trigger Type LOW LEVEL
Logic Type D-Type, Addressable
Current - Output High, Low 24mA 24mA
Halogen Free Halogen Free
Logic Function D-Type, Shift Register
Family AC
Turn On Delay Time 6.5 ns
Quiescent Current 8μA
Propagation Delay 22.5 ns
Number of Bits 8
Max Supply Current 8μA
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Circuit 1:8
Number of Elements 1
Operating Supply Voltage 5V
Output Type Standard
Pin Count 16
Base Part Number 74AC259
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method RAIL
Subcategory FF/Latches
Terminal Finish Tin (Sn)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 74AC
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 665.986997mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 2 Weeks
