MC14042BCPG
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Through Hole RoHS Compliant HIGH LEVEL Obsolete D-Type Transparent Latch 50pF -55C~125C 4.535924g 180ns
PDF
/
Buying Options
Total Price: USD $3.58
Unit Price: USD $3.5834
≥1 USD $3.5834
≥10 USD $2.94025
≥100 USD $2.84905
≥500 USD $2.7569
≥1000 USD $2.66475
Inventory: 15103
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Weight 4.535924g
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2005
Series 4000B
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Tin (Sn)
Subcategory FF/Latches
Packing Method RAIL
Technology CMOS
Voltage - Supply 3V~18V
Terminal Position DUAL
Number of Functions 1
Supply Voltage 5V
Base Part Number 4042
Pin Count 16
Output Type Differential
Number of Elements 1
Circuit 1:1
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 3V
Number of Circuits 4
Load Capacitance 50pF
Output Current 8.8mA
Number of Bits 4
Propagation Delay 180 ns
Quiescent Current 6nA
Turn On Delay Time 60 ns
Logic Function D-Type, Latch
Current - Output High, Low 8.8mA 8.8mA
Logic Type D-Type Transparent Latch
Trigger Type HIGH LEVEL
Dimensions
Height 3.429mm
Length 19.5326mm
Width 6.858mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
