MC10H130FNG
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount RoHS Compliant LOW LEVEL Obsolete S-R Latch 0C~75C 8.965mm 1.7ns -50mA
PDF
/
Buying Options
Total Price: USD $5.32
Unit Price: USD $5.318691
≥1 USD $5.318691
≥10 USD $5.017635
≥100 USD $4.733617
≥500 USD $4.465679
≥1000 USD $4.212904
Inventory: 2735
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Number of Pins 20
Technical
Operating Temperature 0°C~75°C
Packaging Tube
Published 2006
Series 10H
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Terminal Finish Tin (Sn)
Technology ECL
Voltage - Supply 4.94V~5.46V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 10H130
Pin Count 20
Qualification Status Not Qualified
Output Type Differential
Circuit 1:1
Polarity Non-Inverting
Nominal Supply Current 35mA
Number of Bits 2
Propagation Delay 1.7 ns
Turn On Delay Time 1 ns
Family 10H
Logic Function Latch
Output Characteristics OPEN-EMITTER
Logic Type S-R Latch
Prop. Delay@Nom-Sup 1.9 ns
Trigger Type LOW LEVEL
High Level Output Current -50mA
Low Level Output Current 32mA
Number of Input Lines 2
Dimensions
Height Seated (Max) 4.57mm
Length 8.965mm
Width 8.965mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
