MC10E175FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount Non-RoHS Compliant LOW LEVEL Obsolete D-Type Transparent Latch 700MHz 0C~85C 4.57mm 975ps
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4936
≥1 USD $3.4936
Inventory: 399
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Number of Pins 28
Technical
Operating Temperature 0°C~85°C
Packaging Tube
Published 2006
Series 10E
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory FF/Latches
Technology ECL
Voltage - Supply 4.2V~5.5V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 10E175
Pin Count 28
Qualification Status Not Qualified
Output Type Standard
Circuit 9:9
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Number of Circuits 3
Nominal Supply Current 132mA
Number of Bits 9
Propagation Delay 975 ps
Quiescent Current 110mA
Turn On Delay Time 800 ps
Family 10E
Logic Function D-Type, Latch
Output Characteristics OPEN-EMITTER
Logic Type D-Type Transparent Latch
Trigger Type LOW LEVEL
High Level Output Current 50mA
Low Level Output Current 50mA
Number of Input Lines 2
Independent Circuits 1
fmax-Min 700 MHz
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
